Solid-State SP4T Microwave Switch Board

Key Features

• Switch Type: Solid-state SP4T reflective topology
• Switch IC: pSemi PE42546 UltraCMOS® SP4T RF switch
• Frequency Range: 9 kHz – 52 GHz
• Insertion Loss: ~5 dB @ 30 GHz
• Isolation: up to 35 dB typical
• Return Loss: ~-30 dB typical @ 30 GHz
• Switching Time: ~60 ns typical
• Linearity: IIP3 ~52–53 dBm typical
• Input P1dB: ~35 dBm typical
• Operating Temperature: −40 °C to +105 °C
• Board size: 52 mm x 51 mm*
• Control Interface: CMOS compatible logic

Board Overview

This SP4T board integrates the a solid state switch die with an optimized RF layout to support ultra wide band, multi-GHz operation. It includes 2.92mm female connectors and control interfaces to make integration into larger systems straightforward:

• RF Interfaces: 50 Ω 2.92 mm female connectors (board level)
• Control: 3.15 V – 3.45 V CMOS logic compatible
• Power Supply: Single 3.3 V supply for switch IC rail

The board implements proper RF grounding, impedance control, and decoupling to maximize isolation and minimize reflections across the operating band.

Software & Control

• Control Method: Logic pins for switching states
• Automation Support: GPIO / USB support (via host micro/controller).
• Switch Commands: Set active path; Disable all paths; Read state

This board can be easily integrated with Python or embedded control software.

Typical Applications

• RF test and measurement systems
• Millimeter-wave communications (5G FR2)
• Satellite transponder subsystems
• Radar and sensor systems
• Automated test equipment (ATE) routing
• Military systems

Mechanical & Integration

• Board Size: 52 mm × 51 mm
• Connectors: 50 Ω 2.92 mm female
• Mounting Holes: Standard rack/fixture pattern
• Housing: Optional metal/die-cast enclosure

Compliance & Reliability

• RoHS: Yes
• MTBF: XXX hours
• ESD Rating: HBM 2000 V (IC class guideline)

What’s Included

• SP4T microwave switch board with or without casing
• Control interface header
• RF connector set
